The Pony Express 1052 is a self propelled scissor lift cart from Electro Kinetic Technologies that pairs a battery powered drive system with a hydraulic scissor table. One operator can load at floor friendly height, drive the cart across the plant at up to 3 mph, then raise as much as 2500 lb to the exact working height the next station needs. Every push, pull and manual lift that normally happens during a material transfer is handled by the cart instead of a worker.
The signature safety feature is crawl speed. Any time the platform is not fully lowered, the cart automatically limits forward and reverse travel to a quarter of normal speed, so the operator can still nudge a raised load into final position without ever moving fast with a high center of gravity. EK Tech can also configure the cart to lock out travel completely whenever the platform is up.
The 1052 comes in six base configurations that pair a 2000 or 2500 lb capacity with 24, 36 or 48 inches of vertical travel, and every build starts at a low 17.5 inch lowered height. Platforms run from a standard 26 x 40 inches up to a maximum 36 x 84 inches. Because each unit is built to order in Wisconsin, EK Tech engineers routinely tailor the deck, controls and safety package to the application. Working units are in service everywhere from window and door manufacturing to aerospace packaging lines and the Bay Area Rapid Transit system.
| Model Series | Pony Express 1052 with six factory configurations |
| Configurations | 1052-2000-24, 1052-2500-24, 1052-2000-36, 1052-2500-36, 1052-2000-48, 1052-2500-48 |
| Payload Capacity | 2000 lb or 2500 lb depending on build |
| Vertical Travel Options | 24 in, 36 in or 48 in |
| Lowered Platform Height | 17.5 in on every configuration |
| Maximum Raised Height | 41.5 in, 53.5 in or 65.5 in by travel option |
| Standard Platform Sizes | 26 x 40 in, 26 x 48 in or 26 x 64 in |
| Maximum Platform Sizes | 36 x 60 in, 36 x 72 in or 36 x 84 in |
| Lift Time | 7 to 21 seconds depending on configuration |
| Travel Speed | 0 to 3 mph with hi and low speed switch |
| Crawl Speed Safety | Drive speed limited to 25 percent of normal whenever the platform is raised |
| Operating Range | Up to 5 miles per charge |
| Battery | Deep cycle AGM rated for about twice the life of standard batteries |
| Charger | On board UL and cUL listed smart charger, 120 or 240 VAC input |
| Brakes | Regenerative dynamic braking plus automatic holding brake |
| Casters | 8 in casters with non marking tires |
| Controls | Magnetic backed hand pendant with up and down control on a 10 ft cord |
| Standard Safety Equipment | Horn, key switch and emergency stop |
| Construction | Welded steel frame built in Germantown Wisconsin USA |
The Pony Express 1052 is configured to order. Every option below is priced in your quote. Call us toll free at 1-888-233-5563 and we will walk through the choices with you and confirm current pricing and lead time.
Because the 1052 is a factory built custom cart, its accessories are fitted at build time rather than bolted on later. The tops, skirting, sensing edges and enclosure upgrades listed under options are all installed and tested in Germantown before the cart ships. Spare battery packs, replacement casters and charger components are available through EK Tech parts support, and we can include them on your quote so the cart arrives with everything your maintenance team wants on the shelf.
We sell the Pony Express 1052 on a quote basis so we can pair you with the right configuration and the best available price. Call us toll free at 1-888-233-5563 or use our contact form and we will have a quote back to you the same business day in most cases.
Most products in this range do not meet the strict medical device rules that Medicare and Medicaid use, so they rarely qualify for coverage. We do not work with Medicare and we do not bill private insurance directly.
Some private plans will reimburse you outside of the Medicare framework. The best way to find out is to call your insurer and ask. If they say yes, we are happy to provide an invoice and proof of purchase so you can file for reimbursement.
Notice to Medicare and Medicaid beneficiaries. Medicare pays for equipment only when the supplier has a Medicare supplier number. Heavy Duty Mobility does not have one, so Medicare will not pay for anything we sell you. You are personally and fully responsible for payment.
Orders typically leave the warehouse within one to three business days. Once on the way, expect a transit time of around three to seven business days depending on your distance from the warehouse.
The stock status sits just under the product title near the top of this page. If it shows a lead time, the ship out window is that lead time plus the normal transit time above.
Yes. As soon as your order ships we email you a tracking link so you can follow it all the way to your door.
EK Tech backs the Pony Express 1052 with a manufacturer limited warranty. The exact coverage terms for this model are listed in the Specifications tab and the product documentation. Normal wear items and damage from misuse or accidents are excluded, as with all manufacturer warranties.
If something goes wrong, reach out to us first. We can often sort out a fix over the phone or ship a replacement part. Contact us and we will help.
Yes, returns are possible. Please read the full returns policy for the details.
The official EK Tech scissor lift cart brochure covers the full 1052 configuration chart and the option list. Download the EKT Scissor Lift Brochure PDF.
Key safety systems on every 1052
Operators drive the 1052 with a simple hand control mounted at the push handle, with a hi and low speed switch for open aisles versus tight quarters. Platform height is run from a magnetic backed pendant on a 10 foot cord, so the operator can stand wherever visibility is best while raising or lowering the load.
Charging is as simple as it gets. The on board UL and cUL listed smart charger plugs into a standard wall outlet, and an overnight charge supports a full shift with up to 5 miles of driving. The deep cycle AGM battery is rated for roughly twice the service life of a standard battery and never needs watering.
The 8 inch non marking casters roll cleanly over finished floors, and the automatic holding brake keeps the cart planted on ramps and dock plates. These are heavy industrial machines, so every 1052 ships by freight carrier on a skid. We coordinate dock delivery or liftgate service with you when the build is scheduled.
The 1052 comes in 2000 lb and 2500 lb capacity builds. Both capacities are available with 24, 36 or 48 inches of vertical travel, giving six standard configurations, and EK Tech can engineer capacities above 2500 lb on request.
Every 1052 starts at a 17.5 inch lowered height. Depending on whether you choose 24, 36 or 48 inches of vertical travel, the platform tops out at 41.5, 53.5 or 65.5 inches.
Yes, but only at crawl speed. The cart automatically limits forward and reverse travel to 25 percent of normal speed whenever the platform is not fully lowered, which lets the operator fine position a raised load safely. EK Tech can also configure the cart so it will not travel at all with the platform up.
It runs on a deep cycle AGM battery rated for about twice the life of a standard battery. The on board UL and cUL listed smart charger plugs into a regular wall outlet, and a full charge supports up to 5 miles of driving, which covers a typical full shift.
Standard platforms run 26 x 40, 26 x 48 and 26 x 64 inches depending on the lift height, with maximum sizes of 36 x 60, 36 x 72 and 36 x 84 inches. Custom decks such as ball transfer tops, rotating tops, conveyor tops and stainless steel tops are factory options.
Every 1052 is built to order around your capacity, lift height, platform size and option choices, so EK Tech prices each build individually. Tell us about your application and we will return a firm factory quote, usually within a few business days.
The 1050-EL is the light duty model with a 1000 lb capacity and a fixed 23 x 43.5 inch platform. The 1052 is the heavy duty custom line with double the capacity or more, larger platforms up to 36 x 84 inches, an industrial drive system and a much deeper factory option list.
Electro Kinetic Technologies, known as EK Tech, designs and builds its ergonomic material handling equipment in Germantown Wisconsin. The company specializes in motorized carts, electric tuggers and lift carts that remove the push, pull and lift forces behind most workplace musculoskeletal injuries, and it is a member company of MHI, the largest material handling industry association in the US. EK Tech custom builds have been delivered to NASA jet engine service teams, aerospace packaging lines, pharmaceutical clean rooms and the Bay Area Rapid Transit system, which speaks to how far customers trust the engineering. Buying a 1052 means buying a US built machine from a factory that will still be answering parts and support calls a decade from now.
